19.4 Settings Conflicts
Some of the options, parameters and expansion options may require another option, parameter or expansion
option to be set. Please see the below table for these settings conflicts. A setting conflict will result in the MM
being forced into Commission mode.
Setting Conflict Message
(1) (P53, P54, P55, P56) External load sensor incorrectly configured
• The external load sensor must be set with the minimum and maximum values and voltages.
• Check option 1 and parameters 53 – 56.
(1) (81, 83) OTC setpoints too high for optioned load sensor
• If minimum and maximum setpoints OTC setpoints must be set within the possible range of the optioned
load detector.
• Check option 1, 81 and 83.
(9) (45) Internal stat must be disabled if load sensor not present
• If external modulation is enabled without a load sensor, the internal stat must always be closed.
• Check options 9 and 45.
(30) (31) Invalid remote setpoint configuration
• The Minimum Remote Setpoint (DTI/Modbus/External) cannot be set higher than the Maximum Remote
Setpoint (DTI/Modbus/External) and vice versa.
• Check options 30 and 31.
(43) (44) (E1) Water level control only be on the multi-burner master
• Water level control should only be enabled on the master (multi-burner ID 1 set in option 44), when using
the multi-burner function.
• Check options 43, 44 and expansion option 1.
(43) (44) (16) Sequencing only be only the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can be set for sequencing.
• Check options 16, 43 and 44.
(43) (44) (12) EGA and trim can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can be optioned with an EGA.
• Check options 12, 43 and 44.
(43) (44) (E110) First Outs can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can have first outs enabled.
• Check options 43, 44 and expansion option 110.
(43) (44) (E120) Heat-flow can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 44) can have heat flow function enabled.
• Check options 43, 44 and expansion option 120.
(43) (44) (45) External modulation can only be on the multi-burner master
• Only the master (multi-burner ID 1 set in option 4) can be set for external modulation.
• Check options 43 – 45.
(43) (44) (E82) Draught control can only be on the multi-burner master.
• Only the master (multi-burner ID 1 set in option 44) can be set for draught control.
• Check options 43, 44 and expansion option 82.
(43) (44) (47) Cold Start should only be optioned on the Multi-Burner Master
• Only the master (multi-burner ID 1 set in option 44) can be se for cold start.
• Check options 43, 44 and 47
(43) (52) Differential Firing Rate Limit requires Fully-Linked Multi-Burner
• Differential Firing Rate Limit requires Fully- Linked Multi-Burner operation
• Check options 43 and 52
(43) (57) Fuel flow metering must be enabled for multi-burner
• The multi-burner function requires fuel flow metering.
• Check options 43 and 57.
