Automatic Systems SmartLane - CAN End of Bus Circuit Board; Fig. 110 - CAN End of Bus Circuit Board

99
SmartLane
LD1

Green 3.3V presence indicator light LD 14

Yellow Dynamic status light 1 Green
LD 2

Green 5V presence indicator light LD15

Yellow Dynamic status light 1 Red
LD 3

Green Watchdog indicator light LD16

Yellow Dynamic status light 2 Green
LD 4

Yellow CAN indicator light LD17

Yellow Dynamic status light 2 Red
LD 5

Red Failsafe indicator light LD18:

Yellow Dynamic status light Green
LD 6

Green Input 1 activity indicator light LD19

Yellow Dynamic status light Red
LD 7

Green Input 2 activity indicator light LD20

Yellow Dynamic orientation light Green
LD 8

Green Input 3 activity indicator light LD21

Yellow Dynamic orientation light Red
LD 9

Green Input 4 activity indicator light LD22

Yellow Dynamic status light White
LD 10

Green Input 5 activity indicator light LD23

Yellow Dynamic status light Blue
LD 11

Green Input 6 activity indicator light LD24

Yellow Output 2 activity indicator light (EM)
LD 12

Green Input 7 activity indicator light LD25

Yellow Output 1 activity indicator light (EM)
LD 13

Green Input 8 activity indicator light
9.6. CAN END OF BUS CIRCUIT BOARD
This terminator is placed on the CAN connectors of the last DIRAS V3 circuit boards (E1 & R3).
Fig. 110 - CAN end of bus circuit board
