4.8.6. ASSY. - LOGIC BOARD, RIGHT

Fig. 16 - Right board

REF. DESIGNATION

12 AS1190 circuit board - Motherboard

13 AS1603 circuit board - E/S main interface board

16 4-Pole through base
