8. MAINTENANCE
ALL MAINTENANCE WORK ON THE EQUIPMENT MUST BE CARRIED OUT IN ACCORDANCE WITH THE REQUIREMENTS IN
THE SAFETY WARNINGS: CHAP. 2, PAGE 8.
THE GROUND WIRES MUST INTERCONNECT ALL MOVING METALLIC PARTS (NOT BOLTED TO THE FRAME). SPECIAL
ATTENTION SHOULD BE PAID DURING DISASSEMBLY OF THESE ELEMENTS SO AS NOT TO DAMAGE THESE WIRES. IT IS
IMPERATIVE TO RECONNECT THEM DURING REASSEMBLY.
8.1. RECOMMENDED TOOLS
• Wrench or screwdriver TORX - N° 20 (T20, TX20, etc.) ;
• Electrician's toolkit: screwdrivers, pliers, etc. (For electrical connection);
• Mallet (to anchor the equipment to the floor);
• Ratchet wrench + extension + socket set;
• PC + mini USB or RJ45 Ethernet cable or supervision panel. (Optional) (To configure the lanes);
• Set of Allen keys;
• Flat spanner set.
8.2. RECOMMENDED TIGHTENING TORQUE
Recommended torque for tightening screws and nuts, unless otherwise specified:
Type of screw Torque (Nm) Type of screw Torque (Nm)
M2 0.32 M10 43
M3 1.15 M12 75
M4 2.65 M14 119
M5 5.2 M16 182
M6 8.9 M18 250
M7 14.5 M20 355
M8 22 M22 480
Fig. 57 - Tightening torque
53
SmartLane
