8.30. SUMMARY TABLE OF MAINTENANCE PROGRAMMES
NARROW WIDE
MAINTENANCE
A B C D E
1 year
or 1Mo
cycles
2 years
or 2Mo
cycles
3 years
or 3Mo
cycles
4 years
or 4Mo
cycles
5 years
or 5Mo
cycles
Check
Obstacle opening if power cut.
● ● ● ● ●
Electrical connections
● ● ● ● ●
Stability of the unit and the tightening of the
nuts of the floor anchoring clamps
● ● ● ● ●
Wear and tear and dirt on the flap to ensure it
slides correctly and replace it if necessary.
● ● ● ● ●
Kinematic end stops and replace them if
necessary.
● ● ● ● ●
The tightness of the gear motor and bearings
(greased for life).
● ● ● ● ●
Replacement
Unlocking stop of the kinematics. 0/6012/000 0/6012/000
● ● ● ● ●
Single balance spring assembly - narrow unit.
AME-E-0101118-02
or
AME-E-0101118-04
●
Double balance spring assembly - wide unit.
MEC-E-0101125-02
or
AME-E-0101125-04
● ●
Closing flap. ACA-E06987 ACA-E-0102104
●
Guide strip of the closing flap CCH-E11765 CCH-E11765
●
Kinematic end stop. 0/3551/000 0/3551/000
●
Lubrication
Flap pull
● ● ● ● ●
Upper ball of the balancing spring
● ● ● ● ●
Tests via
Maintenance Interface
Diras signal tests (power <1500).
● ● ● ● ●
CAN bus tests (0% error).
● ● ● ● ●
Luminous picto tests (R+G+B+W)
● ● ● ● ●
Passage authorisation tests + passage
● ● ● ● ●
