Single adult

Persons

+ trolley in front

Single child Person running

Elderly person who

naturally leans over

Person

+ trolley & bag

Person + luggage in front/behind Person with backpack

Adult + child in front

Each with a travel ticket

Fig. 39 - Authorized passages

Two (2) people, one after the other

Two (2) people side by side

Fig. 40 - Prohibited passages
