4.7.2. RIGHT UNIT
9
1
11
2
3
4
6
5
8
7
11
12
Fig. 8 - Location of the external components of the Standard SmartLane gate, right
REF. DESIGNATION
1 Mobile obstacle
2 Fixed obstacle
2
3 Glass plate with dynamic status light/RFID logo
4 Front panel with dynamic orientation light
5 Glass plate without dynamic status light / RFID logo
6 Front panel without dynamic orientation light
7 Rear panel
8 Right panel
9 Left panel
11 DIRAS detectors (Receiver) behind a tinted screen
12 Flap
2 If mobile obstacle height ≥ 1200 mm
