4.8.4. OPTIONAL EXTENSIONS
2
7 5
1
3
4
6
10
8
9
7 25
1
3
4
6
10
Fig. 13 - Housing extension Fig. 14 - Housing extension with filler stainless steel panels
REF. DESIGNATION
1 Frame extension
2 Upper panel
3 Cover
4 Front panel
5 Dynamic status light
6 Dynamic orientation light
7 Assy. DIRAS (Transmitter and/or Receiver) high plane
8 Assy. Right extension gate
9 Assy. Left extension gate
10 Optional early detection cell
23
