4.8.7. ASSY. LOGIC BOARD, INTERMEDIATE

Fig. 17 - Intermediate board

REF. DESIGNATION

12 AS1190 circuit board - Motherboard

13 AS1603 circuit board - Main and E/S interface board

14 AS1656 circuit board - Dynamic LED strip

15 AS1605 circuit board - Main and E/S interface board

16 4-Pole through base
