8.10.1. INCREASING THE VISIBILITY OF MOBILE OBSTACLES
Fig. 69 - Self-adhesive checkerboard (AUT-E-0007169)
As soon as the height of mobile obstacles exceeds 1500 mm from the ground, Automatic Systems recommends applying a
chequered sticker to increase the visibility of obstacles and thus prevent users from accidentally hitting them.
This sticker is supplied as standard with every SmartLane product and can therefore be applied to all heights
of mobile obstacles.
The drawing below explains how to place the chequered sticker in order to optimise the visibility of obstacles:
1500
2000
1900
1800
1700
Fig. 70 - Positioning of the checkerboard sticker
