8.30.1. RECOMMENDED SPARE PARTS
The items used below refer to the chapter Chap. 4.8. Location of the internal components, page 20.
ELECTROMECHANICAL COMPONENTS
ITEM NO.: FIGURE NO. DESIGNATION ARTICLE NO. QUANTITY MODEL
Fig. 46 Retro-reflective sensor (5m cable) 0/7107/777 1 All
4 Fig. 47 Analog inductive sensor 0/7140/284 1 All
5 Fig. 47 Cylindrical stop M5x10 (Ø12.5x13.5)
16
0/6012/000 1 All
3 Fig. 47 Cylindrical stop M8x20 (Ø25.5x19)
17
0/3551/000 2 All
Fig. 47 Flap assembly with tie rod (narrow) ACA-E06987 1 Standard
Flap assembly with tie rod (wide) ACA-E-0102104 1 Wide
4 Fig. 15 Frequency inverter 0.37kW 230V 0/7109/257 1 All
Fig. 94 Ass. single balancing spring RSA-E06176-xx
18
1 Standard
Fig. 96 Ass. double balancing spring MEC-E-0101125-xx
19
1 Wide
6 Fig. 15 Stabilised power supply 24VDC 0/7114/108 1 All
12 Fig. 16 & 17 AS1190 circuit board - Motherboard 0/7108/150_TESTE 1 All
13 Fig. 16 & 17 AS1603 circuit board - Main and E/S interface board 0/7108/162_TESTED 1 All
14 Fig. 17 AS1656 circuit board - Dynamic LED strip 0/7115/055 1 All
15 Fig. 17 AS1605 circuit board - Main and E/S interface board 0/7109/268 1 All
Fig. 42 DIRAS Transmitter Circuit Board right AS1642 0/7109/856_QZ 1 All
Fig. 44 DIRAS Transmitter Circuit Board curved AS1642 0/7115/514 1 All
Fig. 43 DIRAS receiving circuit board right AS1643 0/7109/858_QZ 1 All
Fig. 45 DIRAS receiving circuit board curved AS1653 0/7115/515 1 All
0 Fig. 15 Main circuit breaker 0/2191/000 1 All
9 Fig. 15 Circuit breaker protection FI 0/2919/002 1 All
8 Fig. 47 Solenoid H 2406 - F. 24V.DC 100% ED 0/6920/311 1 All
Fig. 38 Ass. LED strip dynamic function lighting 0/7115/052 1 All
Fig. 38 Ass. LED strip dynamic direction lighting 0/7115/053 1 All
For any other parts refer to the SmartLane spare parts catalogue.
For all orders, indicate the information shown on the equipment nameplate that the spare parts are to be used for:
• Serial number
• Model
• Type (left, right, intermediate)
The use of gloves or antistatic wristbands (Electronic Static Discharge) is essential when handling electronic
boards, otherwise the warranty may be lost.
When replacing an electronic circuit board, set its CAN address and the end of bus board ( Electrical Technical
File).
16 Unlocking stop
17 Open/closed mechanical stop
18 The spring assembly depends on the height of the mobile obstacles. Please specify the height of the mobile obstacles when ordering.
19 The spring assembly depends on the height of the mobile obstacles. Please specify the height of the mobile obstacles when ordering.
91
