Automatic Systems SmartLane - Technical Specifications

4.6. TECHNICAL SPECIFICATIONS
Power supply
(1)
Single phase 230 VAC - 50/60 Hz + Ground
Motor Three-phase asynchronous 120 W
Standby consumption 100 W / lane
Operating consumption 150 W / lane
Peak consumption 315 W / lane
Detection
Ensured for users taller than 1 m (however, the safety of persons or objects less than one (1) meter in
height is ensured against unintentional closing of the obstacles).
Materials Cabinet, boards, panels in 304 stainless steel with a minimum thickness of 1.5 mm
Treatment
Internal mechanical parts (frame, connecting rod, crank, etc.) made from metal treated against
corrosion by RoHS electro-zinc plating.
Ambient operating temperature 0 to +50 °C
Extreme storage temperature from -30 to + 80 °C
Ambient relative humidity <95%, without condensation
Operating time
(2)
0.7 seconds, opening time
Minimum 0.8 seconds, closing time, depending on configuration
Impact force
Provided that the mobile obstacles are fitted with silicone protection, the equipment does not exceed
the impact force thresholds prescribed by the future European standard EN17352 (impact forces less
than 400N according to Chapter 6.3, Appendix C).
MCBF 10,000,000 mean cycles between failures, in compliance with recommended maintenance
(3)
MTTR < 30 minutes.
IP 40
Complies with European standards
(4)
(1) Do not connect to a floating network or to a high-impedance earthed industrial distribution network.
(2) Minimum operating time, which can be set, excluding the enabling of the access control system. The passage request memorisation function makes it possible to accelerate the flow:
no closing of the obstacle between two (2) requests.
(3) Maintenance operations are detailed in the product's Technical Manual. ( Chap. 8.28.2, page 87)
(4) The Moving Obstacle Protection Profile option is required to meet the impact force standards.
Each lane is protected by a 10A circuit breaker.
THE POWER SUPPLY MUST BE PROTECTED BY A 16 A CIRCUIT BREAKER + 30 mA DIFFERENTIAL CIRCUIT BREAKER.
STANDARD LANE (MOBILE OBSTACLES H: 1000)
Free passage (L) 600 mm
Left or Right unit, without option Intermediate unit, without option
Net weight (kg) 140 180
WIDE LANE (MOBILE OBSTACLES H: 1000)
Free passage (L) 900 mm
Left or Right unit, without option Intermediate or Hybrid intermediate unit, without option
Net weight (kg) 180 225
