4.8.2. LEFT CABINET

7 6111 11

Fig. 11 - Internal components - Left cabinet

REF. DESIGNATION

1 Frame

2 Assy. DIRAS (Transmitter) low plane

3 Assy. DIRAS (Transmitter) high plane

4 Assy. Fixed obstacle detection (Transmitter)

5 Assy. Logic board, left

6 Assy. Kinematics

7 Assy. DIRAS vertical plane (Transmitter)

11 Fixing clamp

6  ‘Trolley’ type reinforced DIRAS electronic detection option

7 E/R cell if mobile obstacle height = 1200 mm, DIRAS if mobile obstacle height ≥ 1500 mm.
