4.2. DIRECTION OF PASSAGE
A A
B B
Fig. 1 - Direction of passage
4.3. GENERAL DESCRIPTION
The gate is composed:
1. of a retractable pane constituting the barrier to passage,
2. of a cabinet housing the obstacle movement mechanism, the detectors ensuring security and safety, as well as the
electronic logic controlling the unit,
3. optional housing extensions to increase the number of detectors to ensure anti-fraud control and to integrate a ticket
reader or other validator.
2
3
1
Fig. 2 - Illustration of a standard lane configuration with two (2) extensions
