10.2. AUTO-TRANSFORMER - 120 V > 230 V (OPTIONAL)
For countries with a 120 V mains supply, an auto-transformer (1) to increase the voltage is required, as the SmartLane is
designed to operate at 230 V only.
This is attached directly to the main frame.
1
Fig. 114 - Optional auto-transformer (120 V  230 V)
For the wiring of the various elements, refer to the Electrical Technical File (DTE) supplied with the device.
