SmartLane
CN17 ELECTROMAGNET CN20 EMERGENCY CN21 CAN 0
1 +24 VDC 1 + 24VDC 1 + 24VDC
2 S9 2 Elergency 2 GND
3 GND 3 GND 3 CAN +
5 CAN -
CN4 JTAG 5 GND
6 + 24VDC
LD1

Green +5 V activity indicator light LD18:

Green Relay 7 activity indicator light
LD 2

Yellow CAN activity indicator light. LD19

Green Relay 8 activity indicator light
LD 3

Red Integrated security indicator light LD20

Green Output 1 activity indicator light
LD 4

Green Input 1 activity indicator light LD21

Green Output 2 activity indicator light
LD 5

Green Input 2 activity indicator light LD22

Green Output 3 activity indicator light
LD 6

Green Input 3 activity indicator light LD23

Green Output 4 activity indicator light
LD 7

Green Input 4 activity indicator light LD24

Green Output 5 activity indicator light
LD 8

Green Input 5 activity indicator light LD25

Green Output 6 activity indicator light
LD 9

Green Input 6 activity indicator light LD26

Green Output 7 activity indicator light
LD 10

Green Input 7 activity indicator light LD27

Green Output 8 activity indicator light
LD 11

Green Input 8 activity indicator light (Emergency) LD28

Yellow Dynamic status light Blue
LD 12

Green Relay 1 activity indicator light LD29

Yellow dynamic status light Red
LD 13

Green Relay 2 activity indicator light LD30

Yellow Dynamic status light Green
LD 14

Green Relay 3 activity indicator light LD31

Yellow Dynamic orientation light Red
LD15

Green Relay 4 activity indicator light LD32

Yellow Dynamic orientation light Green
LD16

Green Relay 5 activity indicator light LD33

Yellow Output 9 activity indicator light (EM)
LD17

Green Relay 6 activity indicator light
