Installation and Upgrades for DEFINITY ONE and
IP600 Internet Protocol Release 10
555-233-109
Issue 6
December 2001
Install and Cable the Cabinet
1-85Install equipment room hardware for DEFINITY ONE
1
Circuit pack installation
!
WARNING:
When handling circuit packs or any components of a DEFINITY ONE,
always wear an authorized wrist ground strap. Connect the strap to the
ground connector provided on the system cabinet.
NOTE:
All of the circuit pack slots in the CMC are “universal slots.” Any slot can
contain any type of port circuit pack.
Circuit pack slot loading
All of the circuit pack slots in the CMC are “universal slots.” Any slot can contain
any type of port circuit pack with the following exceptions for cabinet A.
1.Install the TN2314 Processor circuit pack in slot 2 of the cabinet. See
Figure 1-41 on page 1-86.
2.A TN744E Call Classifier/Tone Detector circuit pack is required. The
TN744E should be installed in slot 3.
3.Load all port circuit packs. See Table 1-11 on page 1-87 for the
recommended circuit pack layout.
TN2301 Survivable Remote Logic Switch No
TN2306 ATM Interface (Single-Mode) No
TN2308 Direct Inward Dialing Trunk No
Table 1-10. Non-Allowable Circuit packs and Circuit Modules — Continued
Apparatus
code Name Allowable
