Hardware Additions
6-3Add C-LAN functionality
6
Add C-LAN functionality
IP Softphone is available with DEFINITY ONE or IP600. In addition, co-resident
C-LAN functionality can be optionally purchased. The DEFINITY ONE or IP600
WIndows 2000 LAN interface may be used in place of the C-LAN circuit pack for
those cases where DS0 capability through the C-LAN is not required. DCS using
DS0 will still be supported via a separate C-LAN. The Windows LAN interface
(co-resident C-LAN) will also be used to connect CMS, BCMS Vu, and
CentreVu-CT. See the
Overview for DEFINITY ONE Communications System
Release 10
(555-233-005) or Overview for IP600 Internet Protocol Server
Overview Release 10
(555-600-001).
Adding a TN799DP C-LAN circuit pack
To add a TN799DP C-LAN circuit pack, complete the following procedures:
■ Install the TN799DP
■ Test the External Connection to the LAN
■ Administer the TN799DP on the SAT
Installing the TN799DP
To install a TN799DP C-LAN circuit pack, you need the following items:
■ An unoccupied port slot
■ A 10 BaseT ethernet connection into your local area network
■ A valid, unused IP addresses on your network for each C-LAN circuit pack
!
CAUTION:
When adding or replacing any hardware, be sure to ground yourself against
electrostatic discharge (ESD) by wearing a grounded wrist strap.
NOTE:
The TN799DP circuit pack is hot-swappable, so you do not need to power
down the carrier to install it.
From the rear of the cabinet:
1. Connect the 259A connector to the backplane connector corresponding to
the TN799DP slot.
2. Connect one end of the CAT5 cable to the 259A connector. Connect the
other end to the customer’s network.
From the front of the cabinet:
1. Insert the TN799DP circuit pack into the port slot identified earlier.
