Installation and Upgrades for DEFINITY ONE and
IP600 Internet Protocol Release 10
555-233-109
Issue 6
December 2001
Install and Cable the Cabinet
1-51Check customer’s order
1
SECTION II - DEFINITY ONE
INSTALLATION
This section describes procedures for installing the DEFINITY ONE system.
NOTE:
While this section explains how to install DEFINITY ONE on a compact
modular cabinet (CMC), it can also be installed on a 19” rack mounted
cabinet (RMC). See “Section I - Avaya IP600 Installation” on page 3.
Check customer’s order
1. Check the customer’s order and the shipping packing lists to confirm that
all equipment is included.
2. Report missing equipment to an Avaya representative.
3. Check the system adjuncts for damage and report all damage according to
local shipping instructions.
Correct shipping errors
1. Red-tag all defective equipment and over-shipped equipment and return
according to the nearest Material Stocking Location (MSL) instructions.
2. Direct all short-shipped reports to the nearest MSL. Contact the
appropriate location for specific instructions. For streamlined
implementation, call 1-800-772-5409.
Unpack and inspect
!
DANGER:
Use lifting precautions! A fully loaded DEFINITY ONE system with a single CMC
weighs 58 lbs (26.3 kg). If the doors, power unit, and circuit packs are removed, the
CMC unit weighs only 29 lbs (13.1 kg).
1. Verify the equipment received. See Figure 1-23 on page 1-52 Actual
equipment may vary in appearance and may ship in separate packages.
Equipment comcodes are listed in Table 1-8 on page 1-53.
2. Before mounting the cabinet, remove the CMC cabinet doors by opening
and then lifting them straight up and off the hinge pins.
