Installation and Upgrades for DEFINITY ONE and
IP600 Internet Protocol Release 10
555-233-109
Issue 6
December 2001
Install and Cable the Cabinet
1-50Set ringing option for Avaya IP600
1
Figure 1-22. TN2314 circuit pack faceplate
Figure Notes
1. PCMCIA slots
2. Red LED
3. Green LED
4. Amber LED
5. PCMCIA In-Use LED
6. Emergency Transfer Switch
7. Shutdown Complete — safe to pull
board when green LED is on
8. Shutdown Switch — gracefully shuts
down system
Do Not Remove Board Unitl
Shutdown Is Complete
ckdf2314 LJK 090501
On
Auto
Off
In Use
Do Not Remo
ve
Maj Alarm
Min Alarm
Clock
Service
Access
Emergency
Transfer
Complete
Shutdown
6
7
8
3
4
Do Not Remove When In Use
1
2
5
