Installation and Upgrades for DEFINITY ONE and
IP600 Internet Protocol Release 10
555-233-109
Issue 6
December 2001
Install and Cable the Cabinet
1-136Complete installation
1
Complete installation
1. Disconnect the laptop.
2. Remove the RJ45 connector used to connect the laptop.
3. Insert the flash disk.
4. Set the left and right doors of the DEFINITY ONE CMC or the single door
of the Avaya IP600 RMC onto the hinge pins and close the door(s). The
doors must be closed to prevent EMI emissions. Tighten the door screws.
5. For the DEFINITY ONE CMC, set the right cover panel onto the right panel
and secure. Do not use force.
View LEDs to determine power and fan
alarm state
Use the LEDs on the front of each power unit to determine its state.
Table 1-27 shows the LED and alarm conditions. Ring voltage and neon bus
output do not activate alarm status.
Table 1-27. LED and Alarm Conditions
Condition LED status Alarm state Fan alarm
Normal Red off
Yellow on
open high
No Input Power Red off
Yellow off
closed open
One or More DC
Outputs Present
Red on
Yellow off
closed no state
Fan Alarm Red on
Yellow off
closed low
