Overview: BST Phones
1.5.5 M7310
This type of phone can be used for system, centralized and personal administration functions covered by this document.
For system and centralized administration, the phone must be connected to one of the first two extension ports on the
system.
Button Numbering
The diagram below indicates the button functions during normal phone operation. The double digit numbers are the
button numbering for programmable buttons.
10/22
14/26
18/30
11/23
15/27
19/31
12/24
16/28
20/32
13/25
17/29
21/33
Shift
Display
Release
Feature
Hold
SK1
SK2
SK3
1
2
3
09
04
4
5
6
08
03
7
8
9
07
02
*
0
#
06
01
–
Volume
+
05
Mute
· For systems running in key system mode, the first two programmable buttons, 01 and 02, are fixed as Intercom
1 and Intercom 2 buttons. Line buttons, based on the Number of Lines setting or the number of analog
trunks installed in the system, are assigned from buttons 09 downwards and then button 10 upwards.
· For systems running in PBX system mode, the first three buttons, 01 to 03, are fixed as call appearance buttons.
