Note:
For information about IP Office preinstallation data gathering, see Avaya IP Office Platform
10.0 SIP Telephone Installation Notes.
Installing the phone
Before you begin
You must do the following:
• Configure the file server.
• Download and extract the firmware zip file to your file server.
• Configure the 46xxsettings.txt file.
Procedure
1. Set up the phone hardware.
2. Plug the Ethernet cable to the phone.
The phone powers up and starts to initialize.
3. The initialization procedure consists of the following processes:
a. The phone checks for LLDP messages.
b. The phone sends a DHCP DISCOVER message to discover the DHCP server in the
network and invokes the DHCP process.
If the phone does not receive a provisioning server address from the configuration
setup, the phone displays the Configure Provision Server screen.
c. In the Configure Provision Server screen, press the Config softkey and enter the
address of the provisioning server. The provisioning server address can be in the form
of IP address or a Fully Qualified Domain Name (FQDN). To enter the dot symbol (.)
in the field, press the alphanumeric softkey to toggle to the alphanumeric mode.
d. The phone verifies the VLAN ID, and starts tagging the data and voice packets
accordingly.
e. The phone sends and identifies an upgrade script file, gets the Settings file, the
language files, and any firmware updates.
• If configured to use simple certificate enrollment protocol (SCEP), the phone
downloads a valid device certificate.
• The phone displays only the Admin softkey for 15 seconds, and then the Admin
and the Login softkeys.
Note:
For subsequent restarts, if the user login is automatic and the supplied
credentials are valid, the Login softkey is not displayed.
Software installation
December 2018 Installing and Administering Avaya J100 Series IP Phones 39
Comments on this document? infodev@avaya.com
