Operation using the data setting device Azbil Corporation
5-8 Model MTG11A/18A, MTG11B/18B, MTG14C
Totalized value display: An totalized value is displayed in 8 digits without signs and
decimal points.
In the main display, unnecessary zeros are deleted (but are
not deleted in the sub display).
Next to 99999999, totalization starts from 00000000.
5-3-2 : Display of write protect level
Protect level
The write protect levels and their corresponding settings and operating condition are
shown below.
R/W: Read and write (Reads and writes set values.)
R: Read
W: Write
ENABLE: Enabled
Disable: Disabled
ONLY: Only the indicated operation is enabled.
~Note Be sure to turn off the power supply before changing the write protect
level dip switch settings.
Write
protect
level
SW1 SW2
LSC (Key operation) Communication
OPERATOR'S
MODE
ENGINEERING
MODE
MAINTENANCE
MODE
OPERATOR'S
MODE
ENGINEERING
MODE
MAINTENANCE
MODE
0OFFOFF
R/W
ENABLE
R/W
ENABLE
R/W
ENABLE
R/W
ENABLE
R/W
ENABLE
R/W
ENABLE
1ONOFF
R/W
ENABLE
R/W
ENABLE
R/W
ENABLE
R
ONLY
R
ONLY
R
ONLY
2OFFON
R/W
ENABLE
R
ONLY
R/W
ENABLE
R
ONLY
R
ONLY
R
ONLY
3ONON
R
ONLY
R
ONLY
R/W
ENABLE
R
ONLY
R
ONLY
R
ONLY
