Page #150 background imageLoading...
Page #150 background image
Operation using the data setting device Azbil Corporation
5-44 Model MTG11A/18A, MTG11B/18B, MTG14C
5-6-3 : Setting detector information
Set detector information necessary for combination with the converter.
EX value: Each detector has a unique calibration factor (EX value).
This value is determined at shipment in accordance with the actual
flow rate calibration. DO NOT change this value or the flowmeter
output will be incorrect.
Detector type: When measuring the flow rate, select MTG for the detector type. To
perform adjustments and loop checks, select TST for the detector
type.
Bore diameter: Sets the bore diameter (inside diameter) of the detector. The correct
bore diameter is set as factory default setting.
Setting range: Detector constant: 200.0 to 699.9
Detector type: MTG/TST
Bore diameter: 2.5 to 200
Set the detector information in accordance with the following procedure:
Step Procedure Screen
1 Enter ENGINEERING MODE in accordance with
the entry into ENGINEERING MODE (see
section 5-5-10 : on page 5-36). Then press the
or key to display the screen at right.
2 Press the key to set the detector constant.
Using the or key, enter the numeric value
found in the EX column stamped on the
nameplate of the detector to be combined.
3 In addition, press the key to select the detector
type.
Using the or key, select the detector type.
To measure the flow rate, select MTG. To perform
adjustments and loop checks, select TST.
4 Then press the key to select the bore diameter.
Using the or key, select the bore diameter of
the detector.
5 Using the key, move the cursor to the position
under #.
Press the MODE key to return to the
MEASURING MODE and save data.
m CAUTION
You have only ten minutes to return to MEASURING MODE to save the new value before
the system resets it to the previously saved value.
12.3 %
#
MTG DIA 050.0
EX 300.0
12.3 %
#
MTG DIA 050.0
EX 320.0
12.3 %
#
MTG DIA 050.0
EX 320.0
12.3 %
#
MTG DIA 100.0
EX 320.0
12.3 %
#
MTG DIA 100.0
EX 320.0
CM2-MTG300-2001.book 44 ペー
