Operation using the data setting device Azbil Corporation
5-36 Model MTG11A/18A, MTG11B/18B, MTG14C
5-5-10 : Entering ENGINEERING MODE and MAINTENANCE
MODE
Introduction
This section describes how to enter ENGINEERING MODE, in which setup
parameters for the electromagnetic flowmeter are to be configured, and
MAINTENANCE MODE, in which calibration and check are to be carried out.
~Note The mode selection screen may not appear, depending on the settings
of write protect. Operate the write protect switch on the main board,
and then select one from levels 1, 2 and 3 to display the screen for
selecting ENGINEERING MODE only. Select write protect level 0 to
display the screen for selecting both ENGINEERING MODE and
MAINTENANCE MODE. See “5-3-2 : Display of write protect
level”.
The procedure for entering ENGINEERING MODE is shown below.
Step Procedure Screen
1 The screen shown right is a screen display
example in MEASURING MODE (measurement
state).
Press the MODE key.
2 The OPERATOR'S MODE screen appears for
approx. two seconds and then the damping setting
screen appears.
3 Press the key twice to display the screen as
shown.
4 Press the key once to move the cursor to the
position shown on the screen.
5 Press the key.
With the display is changed, ENGINEERING
MODE is active.
The screen appears in approx. two seconds.
20.0 %
01.94 m
3
/h
WP0 00069401
20.0 %
* OPERATOR'S
MODE
20.0 %
*
DAMPING
005.0 s
20.0 %
*
MODE ENTER
ENGINEERING
20.0 %
*
MODE ENTER
ENGINEERING
20.0 %
# ENGINEERING
MODE
20.0 %
# ID SET
XXXXXXXX
CM2-MTG300-2001.book 36 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
