Operation using the data setting device Azbil Corporation
5-60 Model MTG11A/18A, MTG11B/18B, MTG14C
5-6-15 : Setting contact output status
This function is used to set contact output status for normal operation.
This function is effective only when contact output has been selected is the function
specification.
Set range: CLOSE Sets the open collector output to ON.
OPEN Sets the open collector output to OFF.
Default: OPEN
Set the contact output status in accordance with the following procedure:
Step Procedure Screen
1 Enter ENGINEERING MODE in accordance with
the entry into ENGINEERING MODE (See “5-5-
10 : Entering ENGINEERING MODE and
MAINTENANCE MODE” on page 5-36.). Then
press the or key to display the screen at right.
2 Press the key.
3 Using the key, set the contact output status.
4 Press the key to move the cursor to the position
under #.
Press the MODE key to return to the
MEASURING MODE and to save data.
m CAUTION
You have only ten minutes to return to MEASURING MODE to save the new value before
the system resets it to the previously saved value.
12.3 %
# ST. OUT MODE
NORMAL CLOSE
12.3 %
# ST. OUT MODE
NORMAL CLOSE
12.3 %
# ST. OUT MODE
NORMAL OPEN
12.3 %
# ST. OUT MODE
NORMAL OPEN
