Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 5-33
5-5-8 : Selecting flow rate to be displayed in the main display
Select the flow rate to be always shown in the main display. The flow rates other than
that selected for the main display are shown in the sub displays. Thereby, three flow
rates can always be monitored.
% (% flow rate): Displays % flow rate
RATE (Actual flow rate)
Setting range: %, RATE, TOTAL
Default: RATE
Select the flow rate to be shown in the main display in accordance with the following
procedure:
Set Description
% % flow rate
RATE Actual flow rate
TOTAL Totalized value
Step Procedure Screen
1 The screen at right is a screen display example in
MEASURING MODE (measurement state). Press
the MODE key.
2 The OPERATOR'S MODE screen appears for
approx. two seconds and then the damping setting
screen appears.
3 Press the or key to display the screen as
shown on the right.
4 Press the key to move the cursor to the position
for the flow rate display method (%, RATE,
TOTAL). The screen at right shows an example
where % flow rate has been set for the main
display.
5 Press the or key to select a flow rate display to
be set. The screen at right shows an example
where RATE (actual flow rate) display has been
selected.
6 Press the key to move the cursor to the position
under *.
Press the MODE key to return to the
MEASURING MODE and to change to the set
flow rate display.
m CAUTION
You have only ten minutes to return to MEASURING MODE to save the new value before
the system resets it to the previously saved value.
20.0 %
01.94 m
3
/h
WP0 00069401
20.0 %
* OPERATOR'S
MODE
20.0 %
*
DAMPING
005.0 s
20.0 %
*
DISP SELECT
%
20.0 %
* OPERATOR'S
MODE
0.30
*
DISP SELECT
RATE
RATE
0.30
*
DISP SELECT
RATE
RATE
CM2-MTG300-2001.book 33 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
