Operation using the data setting device Azbil Corporation
6-24 Model MTG11A/18A, MTG11B/18B, MTG14C
Setting engineering units: UNITS key
Introduction
The instantaneous flow rate value measured by the converter can be set so that it is
displayed in engineering units according to the control process used.
This setting is applied to both display screens of the display panel of the converter and
the SFC.
The engineering units that can be set are as follows.
When mass flow rate units are set, the specific gravity can be set.
Procedure
Use the following procedure to set engineering units.
Volume flow rate units Mass flow rate units
m^3/h, GPH, l/h, cc/h,
m^3/min, GPM, l/min, cm^3/min,
m^3/day, GPD, kGPD, BPD,
m^3/s
GPH=gals/hr, GPM=gals/min,
GPD=gals/day, kGPD=1000XGPD,
BPD=barrels/day
kg/h, lb/h, kg/min, lb/min, kg/s,
lb/s, t/s, t/min, t/s, g/h,
g/min, g/s
Step
Key Procedure SFC screen
1 Confirm that the SFC is set to
“READY”.
If it is not, press the key to set it
to “READY”
2
Press the key.
Result:
• The currently set engineering unit
appears as shown on the right.
CM2-MTG300-2001.book 24 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
