Azbil VDC User Manual

Operation using the data setting device Azbil Corporation
6-68 Model MTG11A/18A, MTG11B/18B, MTG14C
Calibrating gain constant [GAIN CAL] function
Gain constant of amplifier which is set inside the converter can be calibrated by using
SFC. To do this, Azbil Corporation’s smart calibrator (model MGZ14) will be
required.
Use the following procedure to calibrate the gain constant.
Step Key Procedure SFC screen
1 Confirm that the SFC is set to
“READY”.
If it is not, press the key to
set it to “READY”.
2
or
Press the key to access the
CONFIG functions. Press the
key or key to display the
screen as shown on the right
3
or
Press the key. Press the
key or key to display the
screen as shown on the right
4
Press the key.
For gain calibration press the
key, again.
Connect smart calibrator model
MGZ14 to the converter; (For
connecting and operating smart
calibrator model MGZ14, refer to
its user’s manual CM2-MGZ200-
2001).
CLR
( No )
CLR
( No )
SFCM00006009D
B
CONF
H
NEXT
L
PREV
B
CONF
H
NEXT
L
PREV
SFCM00006020D
SFCM00006122D
ENTER
( Yes )
NON-VOL
H
NEXT
L
PREV
ENTER
( Yes )
NON-VOL
H
NEXT
L
PREV
SFCM00006123D
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006124D
CM2-MTG300-2001.book 68 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
