Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 5-17
5-5-4 : Setting of built-in counter reset value
Reset the built-in counter to start totalization from a value set as the built-in counter
reset value. If this value is set to 1000, the built-in counter starts totalization from 1000
after the counter is completely reset.
If the built-in counter is reset, the built-in counter value just before the reset appears at
the side of PREV on the LCD display.
Set range: None
Default: None
Reset the internal counter in accordance with the following procedure:
Step Procedure Screen
1 The screen at the right is a screen display example
in MEASURING MODE (measurement state).
Press the MODE key.
2 The OPERATOR'S MODE screen appears for
approx. two seconds and then the damping setting
screen appears.
3 Press the key three times to display the screen
shown on the right.
4 Press the key to move the cursor to the position
READY.
5 Press the key to reset.
In 0.5 seconds, the reset is completed with ON
changing to READY.
6 Press the key to move the cursor to the position
under *.
Press the MODE key to return to the
MEASURING MODE and save data.
m CAUTION
You have only ten minutes to return to MEASURING MODE to save the new value before
the system resets it to the previously saved value.
20.0 %
01.94 m
3
/h
WP0 00069401
20.0 %
* OPERATOR'S
MODE
20.0 %
*
DAMPING
005.0 s
20.0 %
* CNT-RESET READY
00000000
PREV
20.0 %
* CNT-RESET READY
00000000
PREV
20.0 %
* CNT-RESET ON
00000000
PREV
20.0 %
* CNT-RESET READY
00123456
PREV
20.0 %
* CNT-RESET READY
00123456
PREV
CM2-MTG300-2001.book 17 ペー
