Operation using the data setting device Azbil Corporation
6-14 Model MTG11A/18A, MTG11B/18B, MTG14C
6-2 : Configuration using SFC communicator
Outline of this chapter
This chapter presents how to operate the SFC.
The description proceeds in the following order:
6-2-1: Before communicating using the SFC
Describes the basic operation method.
6-2-2: Setting using SFC communication (1) - setting using key assigned functions
Describes the basic function and setting method.
Describes communication start, range setting, damping constant setting, auto
zero point adjustment etc. These can be set by using the key assigned functions
(Functions that are directly assigned to each of the SFC keys, refer to next page).
6-2-3: Setting using SFC communication (2) - setting using CONFIG functions
Describes the detailed setting.
Describes the advanced setting for MagneW, screen display, converter
information, pulse output/ contact output switching, high low alarm value,
burnout direction etc. These can be set by using CONFIG function (entered by
pressing the key, refer to page 6-16).
B
CONF
CM2-MTG300-2001.book 14 ペー
