Operation using HART communicator Azbil Corporation
7-44 Model MTG11A/18A, MTG11B/18B, MTG14C
7-4 : Short cut commands and menus for HART
communicator
7-4-1 : Short cut keys
Select the item to set from the table below, and press the item number from the online
menu. You can move to the item, which you want to set quickly.
Basic setting Totalized value setting
Flow unit 132 Totalized value display 14231
Range 133 Totalized reset value 14232
Specific gravity 134 Totalized value reset 14233
Damping time constant 135
Auto zero 136 Emergency setting
Display selection 137 High alarm value setting 14241
Function selection 138 Low alarm value setting 14242
Correction coefficient 139 Contact output status setting 14243
Communication method 1426 Burnout (Analog output) 14215
Burnout (Pulse output) 14225
Detector setting
Detector diameter 1411 Device adjustment
Detector type 1412 Analog current output adjustment 1231
Detector constant 1413 Manual zero 1233
Detector constant C2 1414 Gain adjustment 1234
Pulse output adjustment 1235
Signal processing Excitation current adjustment 1236
Auto spike cut 1432
Moving average processing 1433 Output inspection
Moving average processing time 1434 Analog output check W/calibrator 1221
Low flow cut 1435 Analog output check 1222
Drop-out 1436 Pulse output check 1223
Electrode status sensitivity 1437 Contact output check 1224
Electrode status output mode 1438
Others
Pulse setting Converter status 121
Pulse scale unit 14221 ID setting 131
Pulse scale 14222 Shipping data recovery 1236
Pulse width 14223 Review 15
