Azbil VDC User Manual

Operation using the data setting device Azbil Corporation
5-62 Model MTG11A/18A, MTG11B/18B, MTG14C
5-7-1 : Configuration of OUTPUT CHECK MODE
Introduction
OUTPUT CHECK MODE has the following setting and adjustment items.
For details on the function of items, see the following pages.
Item Content Screen
OUTPUT
CHECK
W/CALIBRATOR
Perform loop checks by using a
calibrator (Model MGZ).
OUTPUT
CHECK
I.OUT
Outputs a fixed value of analog
current output to perform loop
checks.
OUTPUT
CHECK
P.OUT
Outputs a fixed value of pulse output
to perform loop checks.
OUTPUT
CHECK
ST.OUT
Outputs a fixed value of contact
output to perform loop checks.
OUTPUT
CHECK
EX
Outputs a fixed value of excitation
current.
This value was calibrated in the
factory.
DO NOT configure this value.
20.0 %
_
> OUTPUT CHECK
W/CALIBRATOR
12.3 %
> OUTPUT CHECK
I.OUT 100%
12.3 %
> OUTPUT CHECK
P.OUT 100%
12.3 %
> OUTPUT CHECK
ST.OUT CLOSE
12.3 %
> OUTPUT CHECK
EX EX1
