Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 6-15
6-2-1: Before communicating using the SFC
What can be done using the SFC
Introduction
It is possible to communicate with the converter, read data or change settings using the
SFC. The functions available with the SFC include functions directly assigned to the
respective keys and CONFIG functions that are entered by pressing the CONF key.
Key assigned functions
The following are the functions directly assigned to the SFC keys.
ID/DE READ: Starts communication.......................................................6-19
Enter the TAG No. ...........................................................6-21
DAMP: Sets and changes a damping time constant ......................6-23
UNITS: Sets engineering units ......................................................6-24
URV: Sets the output range and correction coefficient ..............6-26
OUTPUT: Displays transmitting output ............................................6-27
Loop check of output signal.............................................6-28
CORRECT: Making zero adjustment...................................................6-29
INPUT: Displays flow measured value .........................................6-30
STAT: Displays self-diagnostics result of the converter .............6-31
SW VER: Displays the software version ..........................................6-35
PRINT: Prints out internal data of the converter ...........................6-36
ACT PRINT: Continuously prints out response result ...........................6-39
A-DE: Switches between digital and analog outputs...................6-41
m CAUTION
Be sure to use the SFC with software version 7.0 or newer. Using earlier versions
may fail to operate the SFC correctly.
CM2-MTG300-2001.book 15 ペー
