Azbil VDC User Manual

Operation using the data setting device Azbil Corporation
5-38 Model MTG11A/18A, MTG11B/18B, MTG14C
5-6 : Configuration of ENGINEERING MODE
Introduction
ENGINEERING MODE has the following setting and adjustment items:
For details on items, see “5-6-1 : Setting ID” to “5-6-15 : Setting contact output
status”.
Item Contents Screen
ID SET Sets ID and TAG No.
FUNC SET Setting of open collector output,
selects pulse output or contact
output.
EX, TYPE, DIA Sets the detector information (Ex
value, detector type, and bore
diameter).
C1, C2 Sets the detector factor.
SPAN Sets the flow rate range.
GRAVITY Sets the specific gravity when mass
flow rate unit is selected.
COEFFICIENT Sets a compensation coefficient for
flow rate calculation.
PLS SCL Sets flow rate (pulse scale) per
pulse.
20.0 %
# ID SET
XXXXXXXX
20.0 %
# FUNC SET
PULSE
20.0 %
#
MTG DIA 200
EX 300.0
20.0 %
# C1
1.0234
1.0000
C2
20.0 %
#
SPAN 7.0690 m
3
/h
1.0000 m/s
20.0 %
# GRAVITY
1.0000
20.0 %
# COEFFICIENT
1.0000
20.0 %
# PLS
200.00 l/P
10.000 Hz
SCL
