Operation using the data setting device Azbil Corporation
5-16 Model MTG11A/18A, MTG11B/18B, MTG14C
5-5-3 : Setting of built-in counter reset value
Set a start value of the built-in counter. The scale of this value is considered as the
weight of the pulse. Carry out the built-in counter reset in Section 5.4.5 to start
totalization from any totalized value.
Set range: 00000000 - 99999999
Default: 00000000
Set an internal counter reset value in accordance with the following procedure:
Step Procedure Screen
1 The screen at the right is a screen display example
in MEASURING MODE (measurement state).
Press the MODE key.
2 The OPERATOR'S MODE screen appears for
approx. two seconds and then the damping setting
screen appears.
3 Press the key twice to display the screen.
4 Press the key to move the cursor to the position
under a target value to be changed.
5 Press the or key to set a desired value.
6 Press the key to move the cursor to the position
under *.
Press the MDOE key to return to the
MEASURING MODE and to save data.
m CAUTION
You have only ten minutes to return to MEASURING MODE to save the new value before
the system resets it to the previously saved value.
20.0 %
01.94 m
3
/h
WP0 00069401
20.0 %
* OPERATOR'S
MODE
20.0 %
*
DAMPING
005.0 s
20.0 %
*
CNT-RESET VALUE
00044444
20.0 %
*
CNT-RESET VALUE
00000000
20.0 %
*
CNT-RESET VALUE
00005000
20.0 %
*
CNT-RESET VALUE
00005000
