Operation using the data setting device Azbil Corporation
5-68 Model MTG11A/18A, MTG11B/18B, MTG14C
5-7-6 : Configuration of CALIBRATION MODE
Introduction
CALIBRATION MODE has the following setting and adjustment items:
Configuration of CALIBRATION MODE requires a dedicated calibrator.
Wrong operation may hinder accurate measurements of the flow rate. To operate in
this mode, contact an Azbil Corp. representative.
Item Content Screen
CAL EX
LOW 3.5 mA
Adjusts 3.5 mA excitation
current.
CAL EX
4.9 mA
Adjusts 4.9 mA excitation
current.
CAL EX
7.0 mA
Adjusts 7.0 mA excitation
current.
CAL EX
11.9 mA
Adjusts 11.9 mA excitation
current.
CAL EX
14.0 mA
Adjusts 14.0 mA excitation
current.
CAL I.OUT
LOW 4.000 mA
Adjusts 4 mA analog current
output.
CAL I.OUT
HIGH 20.00 mA
Adjusts 20 mA analog current
output.
CAL P.OUT
FREQ 90 Hz
Adjusts 90 Hz pulse output.
12.3 %
> CAL EX OFF
LOW 3.5 mA
12.3 %
> CAL EX OFF
4.9 mA
12.3 %
> CAL EX OFF
7.0 mA
12.3 %
> CAL EX OFF
11.9 mA
12.3 %
> CAL EX OFF
14.0 mA
12.3 %
> CAL I.OUT OFF
LOW 4.000 mA
12.3 %
> CAL I.OUT OFF
HIGH 20.000 mA
12.3 %
> CAL P.OUT OFF
FREQ 90 Hz
