Azbil VDC User Manual

Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 5-69
CAL GAIN
ZERO
Adjusts 0 m/s gain.
CAL GAIN
2.5 m/s
Adjusts 2.5 m/s gain.
CAL GAIN
10.0 m/s
Adjusts 10.0 m/s gain.
MANUAL ZERO1 Fine zero tuning for
excitation current 4.9mA.
MANUAL ZERO2 Fine zero tuning for
excitation current 7.0mA.
MANUAL ZERO3 Fine zero tuning for
excitation current 11.9mA/
14.0mA.
Item Content Screen
12.3 %
> CAL GAIN OFF
ZERO READY
12.3 %
> CAL GAIN OFF
2.5 m/s READY
12.3 %
> CAL GAIN OFF
10.0 m/s READY
0.1 %
> MANUAL ZERO1
READY
0.1 %
> MANUAL ZERO2
READY
0.1 %
> MANUAL ZERO3
READY
CM2-MTG300-2001.book 69 ページ ２０１５年９月２９日 火曜日 午前１０時１４分
