Operation using the data setting device Azbil Corporation
5-50 Model MTG11A/18A, MTG11B/18B, MTG14C
Set pulse scale in accordance with the following procedure:
Step Procedure Screen
1 Enter ENGINEERING MODE in accordance with
the entry into ENGINEERING MODE (see
section 5-5-10 : on page 5-36). Then press the
or key to display the screen at right.
2 Press the key to move the cursor to the position
under a desired value to be set or changed.
3 Using the or key, change the value to a desired
pulse scale to be set.
4 Press the key to move the cursor to the position
under #.
Press the MODE key to return to the
MEASURING MDOE and to save data.
m CAUTION
You have only ten minutes to return to MEASURING MODE to save the new value before
the system resets it to the previously saved value.
12.3 %
# PLS 27.780 Hz
100.00 l/pSCL
12.3 %
# PLS 27.780 Hz
100.00 l/pSCL
12.3 %
# PLS 13.890 Hz
200.00 l/pSCL
12.3 %
# PLS 13.890 Hz
200.00 l/pSCL
