Azbil VDC User Manual

Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 5-73
~Note • If the main display shows -2.0%, the zero point value may exceed
-2.0%. Execute Auto zero before manual zero.
Step Procedure Screen
5 Adjust zero point by pushing the  or  key so that the
main display shows 0.0%.
By pushing the
 key once, READY changes to UP
and the zero point value increases 0.05%.
By pushing the
 key once, READY changes to
DOWN and the zero point value decreases 0.05%.
It takes about 20 seconds to change the zero point
value. During manual zeroing, the value in the main
display flashes. If you push the
 or  key again, wait
until the value in the main display does not flash.
Note
Do not keep on pushing the  or  key.
Manual zeroing does not work.
6 Move the cursor to the mode indicator by
pushing  key.
7Push the  key and display the MANUAL
ZERO2 screen.
8 Execute MANUAL ZERO2, as well as
MANUAL ZERO1. (Refer to the Step 2 to 6.)
9Push the  key and display the MANUAL
ZERO3 screen.
10 Execute MANUAL ZERO3, as well as
MANUAL ZERO1. (Refer to the Step 2 to 6.)
11 Push the MODE key and return to the
MEASURING MODE.
0.0 %
> MANUAL ZERO1
READY
0.0 %
> MANUAL ZERO1
UP
0.0 %
> MANUAL ZERO1
DOWN
0.0 %
> MANUAL ZERO1
READY
0.5 %
> MANUAL ZERO2
WORKING
0.0 %
> MANUAL ZERO2
WORKING
0.5 %
> MANUAL ZERO3
WORKING
0.0 %
> MANUAL ZERO3
WORKING
0.5 %
MEASURING MODE
