Azbil VDC User Manual

Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 6-47
7
Press the key.
Result:
• The screen as shown on the right
appears and the set flow rate
display is confirmed.
8
or
Press the key or key to
show this screen (DOWN LOAD).
9
Press the key.
Result:
• The screen to the right appears and
the changed setting is written into
the database of the converter. The
screen returns to step 2.
10
+
To exit this setting function, press the
+ keys.
11
Press the key.
Result:
- Exiting the flow rate display setting
function, the screen returns to the
screen in step 1.
Step Key Procedure SFC screen
MENU
I
ITEM
DE CONF.
ENTER
( Yes )
NON-VOL
SFCM00006051D
H
NEXT
L
PREV
H
NEXT
L
PREV
SFCM00006053D
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006054D
SFCM00006055D
SHIFT
CLR
( No )
SHIFT
CLR
( No )
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
