Azbil VDC User Manual

Azbil Corporation Operation using the data setting device
Model MTG11A/18A, MTG11B/18B, MTG14C 6-75
6
Press the key.
The changed setting is saved on the
SFC.
7
or
Next, set pulse width. Press the
key or key to display
the screen as shown on the right.
Actual pulse scale will be
displayed. Enter the pulse scale
you want to set by pressing the
numeric keys.
8
Press the key.
The changed setting is saved on the
SFC.
9
or
Press the key or key to
display the screen as shown on the
right.
10
Press the key.
Changed setting data is written into
the database of the converter.
11
Press the key and the screen
returns to the screen as in step 1.
Step Key Procedure SFC screen
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006145D
H
NEXT
L
PREV
H
NEXT
L
PREV
SFCM00006146D
SFCM00006147D
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006164D
H
NEXT
L
PREV
H
NEXT
L
PREV
SFCM00006148D
ENTER
( Yes )
NON-VOL
ENTER
( Yes )
NON-VOL
SFCM00006149D
CLR
( No )
CLR
( No )
SFCM00006009D
