Maintenance and troubleshooting Azbil Corporation
8-12 Model MTG11A/18A, MTG11B/18B, MTG14C
Table 8-2 Spare parts for remote-type converter (Model MTG11B)
No. Parts number Parts name
1 80382354-00100 Terminal assembly
2 HS309-230-16000 Screw
3 80383096-00100 Main board
4 80382689-00100 LCD board
5 83958309-00100 Spacers
6 HS311-530-06200 Screw
7 80382637-00100 Main LCD cable assembly
8 80381052-00100 Plug assembly (G1/2)
9 80352997-00100 Plastic gland
10 80356020-10100 Watertight gland assembly (brass Ni plated)
11 80382366-00100 Case (conduit connection G1/2, standard finish)
80382366-00400 Case (conduit connection G1/2, corrosion proof finish)
12 80382673-00100 Cover assemblies (display) (standard finish)
80382673-00200 Cover assemblies (display) (corrosion proof finish)
13 80382673-00300 Cover assemblies (terminal) (standard finish)
80382673-00400 Cover assemblies (terminal) (corrosion proof finish)
14 HS311-230-05000 Screw
15 80382358-00100 Signal cable assembly
16 80382372-00100 Shields plate assembly
17 HS398-204-18000 Screw
