7.2.1 ARM I LOOP MO NIT OR / Armature current demand monitor PIN 133
Note. There is a hidden PIN 718 which contains an unfiltered version of current demand.
7.2.2 ARM I LOOP MO NIT OR / Armature current % monitor PIN 134
Note. There is an unfiltered version of this value on hidden PIN 719.
7.2.3 ARM I LOOP MO NIT OR / Armature current amps monitor PIN 135
7.2.4 ARM I LOOP MO NIT OR / Upper current limit monitor PIN 136
This is the last stage clamp in the block diagram. See 6.8.1 CURRENT C ONTROL / Block diagram.
7.2.5 ARM I LOOP MO NIT OR / Lo wer current limit monitor PIN 137
This is the last stage clamp in the block diagram. See 6.8.1 CURRENT C ONTROL / Block diagram.
ARM I LOOP MONITOR 3
133)ARM CUR DEM MON
133)ARM CUR DEM MON
0.00 %
PARA METER RANGE PIN
ARM CUR DEM MON + /-150.00% 133
Shows the value of the total armature
current demand as a % of full scale.
R R
ARM I LOOP MONITOR 3
134)ARM CUR % MON
134)ARM CUR % MON
0.00%
PARA METER RANGE PIN
ARM CUR % MON + /-150.00 % 134
Shows the value of the average DC arm
current as a % of rated arm amps.
RR
ARM I LOOP MONITOR 3
135)ARM CUR A MPS MO N
135)ARM CUR A MPS MO N
0.0 AMPS
PARA METER RANGE PIN
ARM CUR A MPS MON + /-3000.0 A MPS 135
Shows the value of the average DC
armature current in amps.
R R
ARM I LOOP MONITOR 3
136)UPPER C UR LIM MN
136)UPPER C UR LIM MN
0.00 %
PARA METER RANGE PIN
UPPER CUR LIM MN + /- 150.00% 136
Shows the % value of the scaled upper
current limit in the current clamp block.
ARM I LOOP MONITOR 3
137)LO WER CUR LIM MN
137)LO WER CUR LIM MN
0.00 %
PARA METER RANGE PIN
LOWER CUR LIM MN + /- 150.00 % 137
Shows the % value of the scaled lo w er
current limit in the current clamp block.
