224 PIN number tables
13.3.1.1 UIP5 (T5) SETUP / UIP5 Input range PIN 350 1 of 4 ranges 10 V range 350
13.3.1.2 UIP5 (T5) SETUP / UIP5 Input offset PIN 3 51 + /-100.00% 0.00 % 3 51
13.3.1.3 UIP5 (T5) SETUP / UIP5 Linear scaling factor PIN 35 2 + /-3.00 00 1.00 00 352
13.3.1.4 UIP5 (T5) SETUP / UIP5 Max clamp level PIN 35 3 + /-300.0 0 % 100.00% 353
13.3.1.5 UIP5 (T5) SETUP / UIP5 Min clamp level PIN 3 54 + /-300.00% -100.00% 354
13.3.1.9 UIP5 (T5) SETUP / UIP5 Digital IP, high value for output 1 PIN 355 + /-300.00% 0.01% 355
13.3.1.1 0 UIP5 (T5) SETUP / UIP5 Digital IP, lo w value for output 1 PIN 35 6 + /-300.0 0 % 0.0 0 % 356
13.3.1.1 1 UIP5 (T5) SETUP / UIP5 Digital IP, high value for output 2 PIN 357 + /-300.00% 0.01% 357
13.3.1.1 2 UIP5 (T5) SETUP / UIP5 Digital IP, lo w value for output 2 PIN 35 8 + /-300.0 0 % 0.0 0 % 358
13.3.1.1 3 UIP5 (T5) SETUP / UIP5 Threshold PIN 359 + /-30.000 V 6.00 0 V 359
13.3.1.1 UIP6 (T6) SETUP / UIP6 Input range PIN 360 1 of 4 ranges 10 V range 360
13.3.1.2 UIP6 (T6) SETUP / UIP6 Input offset PIN 3 61 + /-100.00% 0.00 % 3 61
13.3.1.3 UIP6 (T6) SETUP / UIP6 Linear scaling factor PIN 36 2 + /-3.00 00 1.00 00 362
13.3.1.4 UIP6 (T6) SETUP / UIP6 Max clamp level PIN 36 3 + /-300.0 0 % 100.00% 363
13.3.1.5 UIP6 (T6) SETUP / UIP6 Min clamp level PIN 3 64 + /-300.00% -100.00% 364
13.3.1.9 UIP6 (T6) SETUP / UIP6 Digital IP, high value for output 1 PIN 365 + /-300.00% 0.01% 365
13.3.1.1 0 UIP6 (T6) SETUP / UIP6 Digital IP, lo w value for output 1 PIN 36 6 + /-300.0 0 % 0.0 0 % 366
13.3.1.1 1 UIP6 (T6) SETUP / UIP6 Digital IP, high value for output 2 PIN 367 + /-300.00% 0.01% 367
13.3.1.1 2 UIP6 (T6) SETUP / UIP6 Digital IP, lo w value for output 2 PIN 36 8 + /-300.0 0 % 0.0 0 % 368
13.3.1.1 3 UIP6 (T6) SETUP / UIP6 Threshold PIN 369 + /-30.000 V 6.00 0 V 369
13.3.1.1 UIP7 (T7) SETUP / UIP7 Input range PIN 370 1 of 4 ranges 10 V range 370
13.3.1.2 UIP7 (T7) SETUP / UIP7 Input offset PIN 3 71 + /-100.00% 0.00 % 3 71
13.3.1.3 UIP7 (T7) SETUP / UIP7 Linear scaling factor PIN 37 2 + /-3.00 00 1.00 00 372
13.3.1.4 UIP7 (T7) SETUP / UIP7 Max clamp level PIN 37 3 + /-300.0 0 % 100.00% 373
13.3.1.5 UIP7 (T7) SETUP / UIP7 Min clamp level PIN 3 74 + /-300.00% -100.00% 374
13.3.1.9 UIP7 (T7) SETUP / UIP7 Digital IP, high value for output 1 PIN 375 + /-300.00% 0.01% 375
13.3.1.1 0 UIP7 (T7) SETUP / UIP7 Digital IP, lo w value for output 1 PIN 37 6 + /-300.0 0 % 0.0 0 % 376
13.3.1.1 1 UIP7 (T7) SETUP / UIP7 Digital IP, high value for output 2 PIN 377 + /-300.00% 0.01% 377
13.3.1.1 2 UIP7 (T7) SETUP / UIP7 Digital IP, lo w value for output 2 PIN 37 8 + /-300.0 0 % 0.0 0 % 378
13.3.1.1 3 UIP7 (T7) SETUP / UIP7 Threshold PIN 379 + /-30.000 V 6.00 0 V 379
13.3.1.1 UIP8 (T8) SETUP / UIP8 Input range PIN 380 1 of 4 ranges 10V range 380
13.3.1.2 UIP8 (T8) SETUP / UIP8 Input offset PIN 3 81 + /-100.00% 0.00 % 3 81
13.3.1.3 UIP8 (T8) SETUP / UIP8 Linear scaling factor PIN 38 2 + /-3.00 00 1.00 00 382
13.3.1.4 UIP8 (T8) SETUP / UIP8 Max clamp level PIN 38 3 + /-300.0 0 % 100.00% 383
13.3.1.5 UIP8 (T8) SETUP / UIP8 Min clamp level PIN 3 84 + /-300.00% -100.00% 384
13.3.1.9 UIP8 (T8) SETUP / UIP8 Digital IP, high value for output 1 PIN 385 + /-300.00% 0.01% 385
13.3.1.1 0 UIP8 (T8) SETUP / UIP8 Digital IP, lo w value for output 1 PIN 38 6 + /-300.0 0 % 0.0 0 % 386
13.3.1.1 1 UIP8 (T8) SETUP / UIP8 Digital IP, high value for output 2 PIN 387 + /-300.00% 0.01% 387
13.3.1.1 2 UIP8 (T8) SETUP / UIP8 Digital IP, lo w value for output 2 PIN 38 8 + /-300.0 0 % 0.0 0 % 388
13.3.1.1 3 UIP8 (T8) SETUP / UIP8 Threshold PIN 389 + /-30.000 V 6.00 0 V 389
13.3.1.1 UIP9 (T9) SETUP / UIP9 Input range PIN 390 1 of 4 ranges 10 V range 390
13.3.1.2 UIP9 (T9) SETUP / UIP9 Input offset PIN 3 91 + /-100.00% 0.00 % 3 91
13.3.1.3 UIP9 (T9) SETUP / UIP9 Linear scaling factor PIN 39 2 + /-3.00 00 1.00 00 392
13.3.1.4 UIP9 (T9) SETUP / UIP9 Max clamp level PIN 39 3 + /-300.0 0 % 100.00% 393
13.3.1.5 UIP9 (T9) SETUP / UIP9 Min clamp level PIN 3 94 + /-300.00% -100.00% 394
13.3.1.9 UIP9 (T9) SETUP / UIP9 Digital IP, high value for output 1 PIN 395 + /-300.00% 0.01% 395
13.3.1.1 0 UIP9 (T9) SETUP / UIP9 Digital IP, lo w value for output 1 PIN 39 6 + /-300.0 0 % 0.0 0 % 396
13.3.1.1 1 UIP9 (T9) SETUP / UIP9 Digital IP, high value for output 2 PIN 397 + /-300.00% 0.01% 397
13.3.1.1 2 UIP9 (T9) SETUP / UIP9 Digital IP, lo w value for output 2 PIN 39 8 + /-300.0 0 % 0.0 0 % 398
13.3.1.1 3 UIP9 (T9) SETUP / UIP9 Threshold PIN 399 + /-30.000 V 6.00 0 V 399
13.2.5 Block disconnect PIN 4 00 400
15.1.5 Application blocks 401 - 680
Paragraph Menu / Description PIN
Application manual SUMMER 1 401
Application manual SUMMER 2 415
Application manual PID 1 429
Application manual PID 2 452
Application manual PARA METER PROFILER 475
Application manual REEL DIA METER C ALC 483
Application manual T APER TENSION 494
Application manual TORQ UE COMPENS A TOR 500
Application manual PRESET SPEED 523
Application manual MULTIFUNCTIO N 1 to 8 544
