Level sensor without float type 6900-113
97
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
15 Level sensor without float
type 6900-113
Order no.: 362583
15.1 Technical data
Electrical data
Output current
4 … 20 mA
Supply voltage
DC 24 V ± 4 V
Connection
M12-plug 4-pole
Ambient conditions
Operating temperature
-40 … +70 °C
Storage temperature
-40 … +85 °C
Medium temperature
-10 … +140 °C, 143 °C max. 120 Min.
Mechanical data
Housing specification
Stainless steel
Protection class
IP 69K
Process connection
Tri-clamp 2”
Dimensions
See drawing
Accessories
Designation
Order no.
Sensor-Connection cable M12 5 m
365282
Seal Clamp DN50
304621
Clamp-bracket DN2“/50
U495080
Level sensor without flout complete, type 6900-113
362728
