GPRS modem with Magnetic antenna
143
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
25.3 2. GPRS data modem type Telit
GT864-Quad (optional)
 The modem housing (DGND) must not contact the chassis at any point.
For this, the modem is fitted with the isolation set.
 Please also check the floating ground of the aerial adapter or the aerial.
 The shield bar must also not be in contact with the aerial adapter or the
modem housing.
 The length of the modem cable is limited to 10 m. Any measures to
lengthen the cable must be avoided.
25.3.1 Technical Data
Operating voltage
DC 5 ... 36 V / ca. 83 mA bei 24 V
Dimensions
77 x 67 x 26 (L x B x H)
Weight
Approx. 90 g
Mounting
With two oval countersunk head screw M
3x30mm on plastic
Operating temperature
- 30...+ 75 °C
Storage temperature
- 40...+ 85 °C
Ordering details
Designation
Order number
GPRS data modem type Telit GT864-Quad
304264
25.3.2 Terminal assignment for 2. GPRS data
modem
Motherboard from series C
Clamps RS 232_1
Modem cable 4386-306
132 24V_COM
133 RxD
134 CTS
135 TxD
136 RTS
137 AGND
pk
gn
bu
ye
wh
bn + gy
Shield terminal  Shield ye/gn replace
Note:
RS 232_1 corresponds to the interface on the system dev/ttySM1
