GPRS modem with Magnetic antenna
142
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
Inserting the SIM card
1. Open the cover.
2. Open the slot and insert the SIM card.
25.2 Magnetic antenna
Order no.: 360422
Ø 60mm / H: 13 mm
Antenna length: 5 m
Attention:
Fit the antenna in a location with good reception. The magnetic antenna
may not be used in potentially explosive atmospheres..
First enter PIN in configuration then insert SIM card while the system is
switched off.
