Bartec MAK TIGER 3003 - 8.1 Single sample

Compact Controller TIGER Type 6942-10 Serie C
15
Measuring System MAK TIGER 3003 Service manual, SA 131128, 10.03.2020
4.6.1 Power supply
Attention:
Shielded 2.5 mm² cable (16 A fuse, earth and positive branch) is required for the
24 V power supply, including corresponding switch
The solenoid valves, all the measuring sensors and the ticket printer are
supplied by the Controller (see general diagram on page 47).
4.6.2 Inputs
The inputs are user-configurable. The following assignment is recom-
mended:
log.
inv.
Quiescent
state
Designation
Function
1
n
L
MS1
Milk sensor + temperature intake
2
n
L
MS2
Vacuum tank overflow sensor
3
n
L
MS3
Milk sensor inlet/discharge vacuum tank
4
n
L
MS4
Milk sensor transfer pumping
5
n
L
Standby operation on
22
n
L
Group signal overfill monitor
51
n
L
Start button (optional)
52
n
L
Stop button (optional)
4.6.3 Outputs
The outputs are user-configurable. The following assignment is recom-
mended:
log.
inv.
Valve
designation
Function
Pos. in
valve
terminal
1
1
Ejector
Compressed air ejector
MV1
2
2
Air intake
Air for drainage, moving to level
MV2
3
3
V3
Ejector intake stop valve
1
4
4
V4
Restrictor valve (open in home position)
2
5
5
V5
Ejector outlet stop valve
3
6
6
V6
Vacuum tank stop valve
4
7
7
V7
Intake valve
5
8
8
V8
Pump stop valve
6
9
9
V9
Vacuum tank inlet cleaning valve
7
10
10
V10
Discharge cleaning valve
8
11
11
V11
Inlet transfer pumping valve
9
12
12
V12
Discharge transfer pumping valve (optional)
10
13
13
V13
Unmeasured transfer pump valve (optional)
14
14
V14
Transfer pumping stop valve (optional)
11
15
15
V15
Vacuum restrictor
12
